Temperature Switch Application examples _ pharmaceuticals warehouse temperature monitoring system

Yaxun Electronics, for the protection of drug exports, Yaxun for the Shenzhen Free Trade Zone Drug cold storage installation temperature monitoring system introduced.

Shenzhen Free Trade Zone, a pharmaceutical company to use our cold storage temperature monitoring system, The total area of the Treasury up to 10000 m2, Which contains a total volume of 8940m ³ of cold storage.
Medical cold storage Introduction:
The drug storehouse is divided into two room temperature library, Two temperature control library, Four cold storage,
Temperature Switch Application examples
Yaxun drugs cold storage monitoring program:
Monitoring points 107, in strict accordance with the new version of GSP.
The entire system uses a wired way to cloth points, Strictly in accordance with the requirements of GSP flat storage area of 300m2 in the following, At least two monitoring and control points installed terminal;300m2 or more, each additional 300m2 increase at least one control point terminal, Less than 300m2 by 300m2 calculation.  Plane warehouse monitoring and control point of the terminal installation location, Not less than 2/3 of the stack height of the drug shelf or drug stack. The final determination of 107 temperature monitoring points.
Drug cold storage monitoring system using Yaxun digital temperature recorder:
Digital temperature recorder (temperature switch and temperature sensor) using temperature sensing and temperature protection, Automatic temperature protection mode, High precision, stable performance, good consistency, Response speed. Built-in buzzer alarm. All control status LCD display panel with image icons and text descriptions.

Yaxun drugs cold storage monitoring program design:
Digital temperature recorder through a standard RS-232 or 485 serial interface can be formed with the computer multi-point temperature measurement and control system. While its own data storage records, Effectively avoid the monitoring system in the computer failure and communication line failure occurs when the phenomenon of data loss. Temperature sensor automatically determine the communication status, When the communication with the computer is interrupted, Automatically start the recording function, The data at the time of communication interruption is recorded in its own mass memory. When the computer and resume communication, Can be accompanied by software to record the temperature sensor itself, the data into the computer. Large-capacity memory, The temperature data recorded every minute can be continuously recorded for 300 days.

Yaxun drugs cold storage temperature monitoring system Features:
1:  Through the temperature sensor automatic measurement and control technology and data communication technology, To achieve the cold storage temperature data for 24 hours of continuous monitoring, Alarm, record and data storage, query;
2:  temperature monitoring system on-site air conditioning, dehumidifiers, Humidifier and other equipment for automatic control;
3:  Monitor can be on-site alarm, Monitoring host alarm, network alarm, etc . ;
4:  the management of the sub-reservoir area at any time can check the region's history and reality;
5:  the ultimate reach of the Treasury constant temperature and humidity, centralized management, Real-time temperature monitoring.
Yaxun electronics over the years has been committed to the field of temperature monitoring research and development and application, In the pharmaceutical industry, cold storage temperature monitoring has accumulated a wealth of experience. Targeted to the introduction of the pharmaceutical industry temperature monitoring system, Meet the pharmaceutical production and preservation.  Meet the GSP, GMP certification requirements, To help customers successfully passed the relevant national certification.
